TP 125-80/6 A F A BQQE 3kW Single Stage Single Head In Line 6 Pole 415v
BEST ONLINE PRICES
FREEPHONE 0800 112 3134 if you've seen it cheaper.
* Available where Guaranteed Stock Icon Appears Below
Grundfos TP 125-80/6 A F A BQQE Single Stage Single Head In-Line Pump with 6 Pole 415V 3Ph 50Hz, 3kW Motor and flanged connections.
Single-stage centrifugal in-line single-head pump:
- neck rings and impeller made of cast iron
- cataphoresis treatment
- shell coupling
- top-pull-out principle for easy maintenance
- optimized hydraulics
- in-line design with opposite suction and discharge ports enabling mounting in pipework or on a concrete foundation
- corrosion resistant maintenance-free mechanical shaft seal.
- RP 125mm flanged Outlet
IMAGE FOR ILLUSTRATION PURPOSES ONLY.
| SKU | 98743793 |
|---|---|
| Manufacturer | Grundfos |
| Manufacturers Warranty | 2 Years |
| GTIN | 5712600825147 |
| Weight | 267.0 Kg |
| Dimensions | 882mm (h) x 800mm (w) x 509mm (d) |
| Connection Type | 125mm Flanged |
| Motor Size (kW/W) | 3kW |
| Full Load Current (FLC) | 4,05-3,70 A |
| Voltage | 415V 3Ph 50Hz |
| RPM | 975rpm |
| Max Flow | 140m3/hr |
| Max Head | 8m |
| Max Temperature | 120 degrees C |
| Material | Cast Iron |
| Impeller Material | Cast Iron |
