TP 150-260/4 A F A BQQE 18.5kW Single Stage Single Head In Line 4 Pole 415v

SKU
96306153
MRRP £12,637.00 + VAT Our price £7,330.00 (+ VAT) Incl. VAT: £8796.00

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Order within
11
Hours
10
Mins
32
Secs
for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Grundfos TP 150-260/4 A F A BQQE Single Stage Single Head In-Line Pump with 4 Pole 415V 3Ph 50Hz, 18.5kW Motor and flanged connections.

Single-stage centrifugal in-line single-head pump:

  • neck rings and impeller made of cast iron
  • cataphoresis treatment
  • shell coupling
  • top-pull-out principle for easy maintenance
  • optimized hydraulics
  • in-line design with opposite suction and discharge ports enabling mounting in pipework or on a concrete foundation
  • corrosion resistant maintenance-free mechanical shaft seal.
  • RP 150mm flanged Outlet



IMAGE FOR ILLUSTRATION PURPOSES ONLY.

More Information
SKU 96306153
Manufacturer Grundfos
Manufacturers Warranty 2 Years
GTIN 5700835125941
Weight 425.0 Kg
Dimensions 1112mm (h) x 800mm (w) x 623mm (d)
Connection Type 150mm Flanged
Motor Size (kW/W) 18.5kW
Voltage 415V 3Ph 50Hz
RPM 1465rpm
Max Flow 306m3/hr
Max Head 26m
Max Temperature 120 degrees C
Material Cast Iron
Impeller Material Cast Iron
