TP 200-320/4 A F A BQQE 55kW Single Stage Single Head In Line 4 Pole 415v

SKU
96306157
MRRP £23,251.00 + VAT Our price £13,486.00 (+ VAT) Incl. VAT: £16183.20

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Order within
05
Hours
36
Mins
47
Secs
for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Grundfos TP 200-320/4 A F A BQQE Single Stage Single Head In-Line Pump with 4 Pole 415V 3Ph 50Hz, 55kW Motor and flanged connections.

Single-stage centrifugal in-line single-head pump:

  • neck rings and impeller made of cast iron
  • cataphoresis treatment
  • shell coupling
  • top-pull-out principle for easy maintenance
  • optimized hydraulics
  • in-line design with opposite suction and discharge ports enabling mounting in pipework or on a concrete foundation
  • corrosion resistant maintenance-free mechanical shaft seal.
  • RP 200mm flanged Outlet



IMAGE FOR ILLUSTRATION PURPOSES ONLY.

More Information
SKU 96306157
Manufacturer Grundfos
Manufacturers Warranty 2 Years
GTIN 5700835125989
Weight 803.0 Kg
Dimensions 1419mm (h) x 900mm (w) x 721mm (d)
Connection Type 200mm Flanged
Motor Size (kW/W) 55kW
Voltage 415V 3Ph 50Hz
RPM 1485rpm
Max Flow 736m3/hr
Max Head 32m
Max Temperature 120 degrees C
Material Cast Iron
Impeller Material Cast Iron
