TP 40-140/4 A F A BQQE 1.1kW Single Stage Single Head In Line 4 Pole 240v

Name: TP 40-140/4 A F A BQQE 1.1kW Single Stage Single Head In Line 4 Pole 240v
Brand: Grundfos
SKU: 98760159
Price: 1673 GBP
Availability: InStock

SKU

98760159

MRRP £2,883.00 + VAT Our price £1,673.00 (+ VAT) Incl. VAT: £2,007.60

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Choose Flange Set Option

Choose Bellow Set Option

Choose Gasket Set Option

Qty

Order within

Hours

Mins

Secs

for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Overview & Spec

Grundfos TP 40-140/4 A F A BQQE Single Stage Single Head In-Line Pump with 4 Pole 240V 1Ph 50Hz, 1.1kW Motor and flanged pump connections.

Single-stage centrifugal in-line single-head pump:

neck rings and impeller made of stainless steel
cataphoresis treatment
shell coupling
top-pull-out principle for easy maintenance
optimized hydraulics
in-line design with opposite suction and discharge ports enabling mounting in pipework or on a concrete foundation
corrosion resistant maintenance-free mechanical shaft seal.
RP 40mm flanged Outlet
Optional union sets available, see accessories below for options.

IMAGE FOR ILLUSTRATION PURPOSES ONLY.

More Information
SKU	98760159
Manufacturer	Grundfos
Manufacturers Warranty	2 Years
GTIN	5712600991446
Weight	68.0 Kg
Dimensions	587mm (h) x 440mm (w) x 297mm (d)
Connection Type	40mm Flanged
Motor Size (kW/W)	1.1kW
Full Load Current (FLC)	7 A
Voltage	240V 1Ph 50Hz
RPM	1440rpm
Max Flow	22m3/hr
Max Head	14m
Max Temperature	120 degrees C
Material	Cast Iron
Impeller Material	Cast Iron
