Wilo Yonos MAXO 30/0,5-10 220 DN32 PN6/10 Single Head Circulating Pump 240v

SKU
2210113
MRRP £1,197.00 + VAT Our price £826.00 (+ VAT) Incl. VAT: £991.20

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Order within
Hours
Mins
Secs
for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Wilo Yonos MAXO 30/0,5-10 220 DN32 PN6/10 Single Head Circulating Pump 240v - 2210113

High efficiency pump Wilo-Yonos MAXO

Electronically controlled

Glandless circulator, synchronous motor according to ECM technology and integrated power control for continuous differential pressure control.

Can be used for all heating, ventilation and air-conditioning applications.

Standard-equipped with:
Preselectable control modes for optimum load adjustment: Δp-c (differential pressure constant), Δp-v (differential pressure variable)
3 speed stages (n = constant)
LED for setting the setpoint and displaying error messages
Electrical connection with the Wilo plug
Fault lamp and contact for collective fault signal

For flange-end pumps - flange versions:

Standard version for pumps DN 32 to DN 65:

PN6/10 combination flange (PN 16 flange according to EN 1092-2) for PN6 and PN16 counter flanges

Standard version for DN 80/DN 100 pumps:

PN6 flange (designed for PN 16 according to EN 1092-2) for PN6 counter flange

More Information
SKU 2210113
Manufacturer Wilo
Manufacturers Warranty 2 Years
Weight 9.4 Kg
Dimensions 219mm (H) x 220mm (L) x 102mm (D)
Connection Type 32mm Flanged
Motor Size (kW/W) 5-190watts
Full Load Current (FLC) 1.5A Rated Current
Voltage 240V 1Ph 50Hz
Max Flow 9m3/hr
Max Head 10mtr
Max Temperature 110oC
Material Cast Iron
Impeller Material PPE/PS-GF30
